loading and unloading, on the wheel, really labor-saving

This kind of machine is available for cutting at anydirection:horizontal,vertical and acclivitous, is suitable for quarry to mine large specification and regular blocks,such as marblegranite,quartzite,basalt etc. also good for bridgereinforced concrete and other construction cutting. It with high efficiency, cutting current are automatic controlled, Famous international components，Easy operation and very low cost for maintenance.

This machine is improved on the basis of the original double mining machine. The main shaft is lifted and lowered using four cylinders as guide rails, and the hydraulic cylinder is used to lift and lower. The main advantages are: small clearance, less wear, no vibration, stable structure of the whole machine, and high cutting precision Improve the service life of the cutter head. The cylindrical guide rail is fully enclosed and protected to ensure that the guide rail pollution is reduced. With the special lubrication system, it is beneficial to improve the service life and utilization rate of the machine, and reduce the number of maintenance and costs. It is a comprehensive benefit. Significantly improved mining and quarrying machinery.

This chain saw is composed of a cutting system mounted on a wheel loader. The machine is self-contained, quickly moving and positioning in front of the block or to the bench to be cut. There is no need to prepare an area reserved to the squaring of the blocks in the quarry, as the machine can easily and quickly reach the blocks to be cut. It can work in dry conditions, without using any water to cool the cutting tools. The operator can use a wireless control for all the functions of the machine, which can be used either inside the heated/air-conditioned control cabin or outside the machine.

Chain saw for crawler is the enhanced one of orbital-type chain saw, the biggest characteristic of the machine is equipped with a pedrail walking itself, moving conveniently and flexibly.

The rail type quarry chain saw machine is the most basic and popular model in the world, its rails are placed on the surface of mining or body, and the rails are used alternately. Dry cuts, no water supply required. The products are referred to Italy mainstream manufacturers’design, reasonable layout and structure, convenient operation.

This chain saw designed to open and develop underground mines of marble and of similar stone materials. Underground mining development is becoming a more and more common practice in many marble quarry operations. This method is often considered preferable to the open pit quarrying in terms of production optimization, efficiency, safety and environment preservation. The machine is mounted on a crawler and it can move easily and autonomously inside the tunnel. The machine is configured as shown in the next figures to reduce the overall dimensions and to move over slopes up to 25%. All the movements of the crawler and the positioning devices of the machine are made possible by an on-board “power pack” unit equipped with a diesel engine. During the cutting operation, the machine should be simply connected to the  power line through cable and on-board plug. All the functions are controlled by means of a remote control board without cable and of a touch-screen panel. This machine is compact for tunnel mining work. By setting the cutting depth in automatic mode, the machine can make vertical and horizontal cuts on the tunnel face. This is self-propelled on crawler tracks and moves completely autonomously. Only one operator is required to operate the machine. This model can run cuts as deep as 1.7 meters.

Thin Veneer is made by using a this special saw to cut the machine split stone to a thickness of 1”-1.75” while preserving the natural or split face of the stone.

This machine is designed based on the structural principle of a vertical lathe. It is mainly used to process various stone column caps, column bases, balls, etc. It adopts microcomputer automatic copying, lifting and lowering to adjust the cutting characteristics, which makes up for the high consumption of manual processing. , The defect of poor accuracy, advanced technology, reduce the processing cost.

This machine adopts microcomputer (numerical control) control, one or three frequency converters for speed regulation, bridge structure, synchronous lifting and left and right walking, convenient operation, practicality and high efficiency. It is specially used for processing railings, columns, balusters, column caps, blocking stones and other products.

This machine is optimized and improved on the basis of the combined saw. The machine adopts a four-column hydraulic locking structure, which has good overall rigidity and small clearance, which is conducive to reducing the shaking during the cutting stone, and the produced slabs have high precision. , the flatness is good. At the same time, it has achieved remarkable results in improving the service life of the segments and reducing power consumption.

The machine automatically tracks model of curve(straight) line through the fiber optic probe,automatically profiles through diamond circular saws to cut stone with curve(straight) line and craft products,uses inverter to control up-down rising and left-right feeding, adjusts the speed according to the stone material. If choosing rotating worktable, the processing of arc-shaped lines can be done. This machine adopts PLC system, high degree of automation, high precision cutting; using double-blades designing, with high cutting efficiency, high stability, easy-operation to suit for lines, arc-shaped lines, Roman column,etc. Note: Could choose CNC system, replacing the trouble of making a model, cutting effect more automatically and accurately.
