Automatic Quartz Sink Hole Cutting Machine

It is suitable for drilling and shaping of artificial stone, quartz stone and other plate countertops, and can be polished after changing the tool.This machine adopts high-speed electric spindle, pneumatic clamping; manual feeding and discharging, pneumatic quick clamping, automatic processing, easy to operate.Using PLC control, automatic feeding, automatic positioning, automatic clamping, automatic hole forming, automatic waste discharge and discharge.
  • Item NO.:

    K7026-3T-1
  • Order(MOQ):

    1
  • Payment:

    T/T
  • Product Origin:

    China
  • Color:

    Yellow & gray
  • Shipping Port:

    Xiamen port
  • Lead Time:

    25 days
Product Detail

Product Introduction

Scope of application: High-performance automatic assembly line opening and chamfering equipment developed for artificial stone, quartz stone, marble and  countertop processing industry.

Equipment functions: table top stove hole, above counter basin, Taichung basin, under counter basin, back wall pack with missing corner cut, and oblique joint joint cut.

Basic processing: The equipment is welded and annealed by integral steel pipe. The machining machine is a Japanese Mazak five-axis CNC gantry milling machine, which effectively guarantees the service life and machining accuracy of the equipment.

Configuration selection: The core mechanical and electrical components are all imported or domestic first-line brands, which effectively guarantees the operational stability and quality of the equipment.

Fool-type operation: The control system is independently developed by Longhan's own software department, and the equipment can reach the fool-like operation, effectively avoiding the problem of high entry threshold caused by the low quality of the practitioners. The automatic processing of automatic feeding and discharging of the assembly line has greatly met the current development trend of the countertop industry, effectively reducing the processing dust of the factory, improving the standardization of the products, and the requirements for the operators to be used without differentiation.

Processing quality assurance: This Quartz Sink Hole Cutting Machine adopts three-knife automatic switching and on-line processing design, which is easy to operate, high in processing efficiency and good in quality.

This  machine is the primary choice for standardized countertop processing plants!


Technical Parameters


Quartz Sink Hole Cutting Machine

Type

unit

K7026-3T

             Machine width

mm

2100

Machine Length

mm

4500

Machine Height

mm

1800

Size Width of Machinable Plate

mm

550-700

Size Length of Machinable plate

mm

600-2600

Size Height of Machinable Plate

mm

12-20

Airway velocity parameters

mm/min

12000

Machining speed parameters

mm/min

1000-4000

Total Power Parameters

kw

11

Operating Voltage Parameters

v

AC380

Motor

/

Customized 7.5KW motorized spindle

Motor speed

rpm/min

24000

Control system

/

Longhan KL Professional Edition

Tool Change Type

/

Three-end pneumatic tool change

Control cabinet

/

Independent cabinet

Frequency conversion type

/

Customized Vector Frequency Converter

Driver type

/

Customized Servo System

Feeding mode

/

Automatic Pipeline

Automatic Quartz Sink Hole Cutting Machine

Processing

Automatic Quartz Sink Hole Cutting Machine

Features

batch / special shape / Smarter

Suitable for processing: basin hole / stove hole / countertop middle basin



Non-standardized mass production

Mass production of bathroom basins



Running water trough

High standard



Smart processing

Miter missing corner
